TPX MCPHERSON

PROFESSIONAL MOTORSPORT RALLY TPX MCPHERSON

Öhlins TPX technology is now available to customers in the Rally and RallyX markets. The Öhlins ALR TPX dampers have proven themselves in the toughest conditions, delivering top-tier performance in both disciplines. This product range, featuring a set of universal struts, is specifically aimed at the rally and rallycross markets.

These dampers are fully pressure-balanced, eliminating the risk of cavitation. Thanks to low gas pressure, they maintain low internal friction for improved response and consistency. A wide range of optional components is available to tailor the struts to specific setups. The struts can be built and modified to suit nearly any rally or rallycross vehicle—and they've been winning since day one.


TWIN-PISTON DAMPER (TPX)

The strut is a twin-piston MacPherson design (TPX44) featuring a 44 mm diameter piston. It offers three-way adjustment: one-way rebound and two-way compression.


SPECIFICATIONS:

•    Twin-Piston Technology
•    44 mm piston
•    Piggy back reservoir
•    3-way adjustable
•    McPherson strut
•    Fully pressure balanced
•    PDS (Progressive Damping System)
